Mantaray Bay
Images from SUV Caravans
- From
- $62,995
- Max weight (ATM)
- 3,000kg
- Sleeps
- Up to 3
- Length
- 6.75 m
Floor plans
About the Mantaray Bay
The SUV Caravans Mantaray Bay is a 6.75 metre pop-top caravan that sleeps two or three. The third person sleeps on the cafe lounge, which converts to an extra bed, and the main bed is a king. SUV Caravans lists it for couples and families.
Who does it sleep?
- Main bed: a king bed with an innerspring mattress.
- Extra bed: the cafe lounge and table convert to a sleeping space.
Bathroom and kitchens
The internal ensuite has a separate toilet and shower cubicle. Inside, a kitchenette has an induction cooktop, a rangehood, a sink and a 50 litre mini fridge. The outdoor kitchen has a four-burner gas stove, with pantry drawers and a stainless steel fold-down bench.
Roof and setting up
The roof lifts electrically, and the step folds down electrically too. With the roof closed the van is 2.73 metres high, and 3.25 metres open. The full-length awning rolls out electrically.
Chassis and running gear
- Chassis: fully galvanised, with an Australian engineer approved chassis, drawbar and suspension.
- Suspension: Series 4 recovery suspension with galvanised swing arms, twin shocks and heavy-duty springs.
- Brakes: 12 inch electric brakes and a breakaway system.
- Wheels: 16 inch rims with 265/75R16 all-terrain tyres, and a spare underneath.
- Hitch: an Alko hitch for a 50mm ball.
- Carrying: a rear bike or hitch receiver, jerry can holders, and an external generator slide.
Power and water
SUV Caravans describes it as fully off-grid capable.
- Solar: 600 watts of roof panels.
- Batteries: 405 amp hours of lithium batteries.
- Inverter: a 2000 watt Renogy inverter.
- Charging: a 30 amp smart charger, and a Renogy 50 amp DC-DC charger with a 50 amp solar charge controller.
- Water: two fresh tanks of about 180 litres in total, and a 70 litre grey tank, both monitored.
- Gas: integrated gas hot water and holders for two 4kg bottles.
- Cooling: roof-mounted reverse-cycle air conditioning.
Optional extras
- Heating: a diesel heater.
- Annexe: enclosable, with a floor, walls, skirt and anti-flapper kit.
- Hitch: a DO35 hitch.
- Toilet: a composting toilet.
- Spare: a rear spare tyre and mounting bracket.
- TV: a 12 volt smart TV.
What will tow it?
- ATM (aggregate trailer mass): 3,000kg, the most it can weigh fully loaded.
- Tare: 2,440kg, its empty weight.
- GTM (gross trailer mass): 2,790kg on its own wheels.
All of these weights are approximate, SUV Caravans says. To tow it fully loaded, your vehicle needs a braked towing capacity of at least 3,000kg.
Warranty and where to buy
- Warranty: 12 months from delivery, on defects in material and workmanship.
- Chassis: a 5-year fatigue warranty, from 2025 onwards.
- Cover: new units only, non-transferable.
SUV Caravans is Australian-owned, and designs and assembles its vans in Australia from globally sourced components. You can buy through its showrooms in Caboolture, Cairns, Coffs Harbour, Rockhampton and Townsville.
Technical specifications
About SUV Caravans
SUV Caravans sells off-road caravans, pop-tops and camper trailers. It has showrooms in Queensland and New South Wales, including Caboolture, Cairns and Coffs Harbour. Its range runs from compact hybrids for couples to family vans with triple bunks, and camper trailers with slide-out beds.
